Vaccum Contactor Capacitor Switch

Technical Specifications — VCS

Characteristics	Value
Rated Voltage	12 kV
Rated Current	200 A
Capacitor Switching Current	100 A
Power Frequency Withstand Voltage	28 kV RMS
Impulse Withstand Voltage	75 kV Peak
Frequency	50 Hz
Rated Short-Time Withstand Current	10 kA for 1 second
Rated Making Current	25 kA Peak
Degree of Protection	IP55
VCS Dimensions — Width	700 mm
VCS Dimensions — Depth	815 mm
VCS Dimensions — Height	1115 mm
Weight	170 kg
