Thyristor Module

Description	SHR-25 STM
Rated kVAr	25
Auxiliary Supply	220 VAC
Control DC Supply	12V / 24V DC / TTL
Control Current Consumption	< 5 mA
Over Blockage Voltage	1800 V / 2200 V (Optional)
Operating Mode	Zero Differential Voltage
Indications	Switch ON, Temperature Indication
Weight	4.6 kg
Cooling	Forced Air
Protection Class	IP 00
Frequency	50 Hz / 60 Hz
Humidity	10–95% without Moisture
Protection	Over-Temperature, dv/dt
Maximum Temperature Class — At Rated Load	−10°C to 50°C
Maximum Temperature Class — At 75% Load	−10°C to 60°C
