Single Phase Capacitor Switch

Technical Specifications

Characteristics	Value
Rated Voltage	15 kV
Rated Current	400 A
Capacitor Switching Current	200 A
Power Frequency Withstand Voltage	36 kV RMS
Impulse Withstand Voltage	95 kV Peak
Frequency	50 / 60 Hz
Rated Short-Time Withstand Current	10 kA for 1 second
Rated Making Current	25 kA Peak
Degree of Protection	IP55
Creepage Distance – Terminal to Terminal	564 mm
Creepage Distance – Terminal to Ground	499 mm
Height	812.5 ± 10 mm
Weight	21 kg
