Pole mounted Capacitor banks are installed at the 11KV & 33KV distribution lines to improve power factor and to maintain voltage profile. This is one of the effective installations for reactive power compensation and it's available as fixed or switched system. In switched system bank is switched by solenoid type capacitor switch and it's operated by P.F. correction relay. capacitor units are mounted on racks which are fixed on double pole/single pole structure. Banks are provided with accessories like current & potential transformers, surge arresters on each phase & weather resistance controllers box (unit).
Design Feature:
- 16 x 2 LCD backlit display for parameters and setting display.
- Wide range of auxiliary power supply input from 100V to 300V AC and 0-30V DC.
- Up to 08 nos. programmable output for controlling capacitor banks.
- Standard 144 X 144 cabinet for panel door flush mounting.
- Continuous monitoring internal hardware and indicated as WD (Watch Dog).
- On site CT secondary selection 1A or 5A.
- Bicolor LED Indicate fault & step status.
- Separate Error indication with message
