| Rated Voltage |
12 kV |
| Power Frequency Withstand Voltage |
28 kV RMS |
| Impulse Withstand Voltage |
75 kV Peak |
| Rated Normal Current |
1250 A |
| Rated Short-Circuit Breaking Current |
26.3 kA |
| Rated Short-Time Withstand Current |
26.3 kA for 3 seconds |
| Rated Making Current |
65.8 kA Peak |
| Rated Operating Sequence |
O – 0.3 sec – CO – 3 min – CO |
| Opening Time |
< 60 ms |
| Total Break Time |
< 70 ms |
| Closing Time |
< 80 ms |
| Contact Stroke |
6–8 mm |
| Panel Width |
630 mm |
| Panel Depth |
1535 / 1835 mm |
| Panel Height |
2005 mm |
| Panel Weight with Breaker |
700–1000 kg |
