| Auxiliary Supply |
110–550 VAC, 42–70 Hz |
| Measurement Supply |
30–550 VAC, 42–70 Hz |
| Relay |
250 V, 1000 W |
| Current Input |
1 A / 5 A, Single CT |
| Current Measurement |
10 mA–5 A |
| Display |
16 × 2 Line Graphical LCD Display |
| Operating Temperature |
−10 to 60°C |
| Weight |
0.5 kg |
| Mechanical Dimension |
4 Stage: 96 × 96 × 56 mm6 / 8 / 12 Stage: 144 × 144 × 56 mm |
| Protection Class |
Front Side: IP-54Back Side: IP-20 |
| P.F. Correction Time |
10–1800 Sec. |
| Discharge Time |
60–1800 Sec. |
| Standard Compatibility |
Safety Standard: IEC 61010-1EMC Standard: IEC 61326 |
| Communication Port |
RS-485 (Optional) |
